RPA4-SLW

USE OF PRODUCT
The 4" Prime Wall Wash Series Downlight is the ideal product for energy efficient lighting in commercial and residential applications where wall washing is required. Available in an assortment of color temperatures, optics, lumen outputs, and dimmable driver options.

LED ENGINE
LED engine available in 2700K, 3000K, 3500K, or 4000K in standard 90+ CRI. 2-step MacAdam ellipse allows for color consistency between fixtures. The LED is mounted to an aluminum heat sink for maximum life output and thermal management. Light engine provides a quick disconnect with locking strain relief to housing.

FRAME CONSTRUCTION
IC and Non-IC rated housing are constructed from a 16-gauge heavy-duty, powder-coated cold-rolled steel frame and includes a junction box with ½" knockouts. Butterfly brackets (included) accommodate universal, C-channel, or flat bar hangers (order separately).

ADJUSTMENT
- Light engine locked at 20° tilt, consult factory for other tilt setting.
- Housing provides for 359º locking rotation
- Aperture collar compatible up to 1½" ceiling thickness.
- Accommodation for 2” or 3” ceiling thickness available upon request.

OPTICS
Field replaceable optical lens available in 15º, 24º, 36º, 50º and 80º. Easily achieve narrow spot to wide flood beam pattern. Option for frosted, honeycomb, or solite filter (2 Maximum).

DIMMING
Available in 7 driver selections. (ID) Standard all-inclusive ELV, Triac, and 0-10V dimming driver called Intelligent Drive, 120-277V. (PEQ0) Lutron Hi-Lume Premier Ecosystem 0.1% w/soft on, fade to black dimming, 120-277V. (LDE1) Lutron Hi-Lume 1% Ecosystem with soft on, fade to black dimming, 120-277V. (L3DA) Hi-lume 1% EcoSystem/3-Wire L3D Driver (EEI) eldoLED Eco 1% Dim (0-10V), 120-277V. (EDIO) eldoLED Solo 0.1% Dim(0-10V), 120-277V. (EDID) eldoLED Solo 0.1% Dim(DALI), 120-277V

THERMAL MANAGEMENT
Ambient temperatures at fixture location should not exceed
-20° to 40°C.

EMERGENCY BATTERY
Optional 8W or 15W emergency battery available for a minimum of 90 minutes with both integral or remote test switch.

TRIM
Flange trims available in die-cast or anodized aluminum. Trim includes standard frosted acrylic diffuser. Remove standard frosted acrylic diffuser in field for 7% lumens increase. Optical enhancer reflects light evenly across the diffusion lens. Consult factory for made-to-order finishes. Wet location for bathrooms and showers with standard lens on trim.

LABELS/COMPLIANCE/WARRANTY
- CSA Listed for US and Canada
- Energy Star
- Dry/Damp/Wet location rated.
- Title 24, JA8 Compliant
- 5 Year limited warranty
